Geosynthetics Polypropylene PP Tube Bag Geotube For Sludge Dewatering Dam Dikes Coastal Breakwater
Geotextile tube is manufactured from woven high tenacity polypropylene multifilament yarns or flat monofilament yarns, which are woven into a stable network such that the yarns retain their relative position. Geotextile tube is inert to biological degradation and resistant to naturally encountered chemicals, alkalis, and acids, etc.
Iterm | Unit | Standard | Index | |||
HT500 | HT750 | HT1000 | ||||
Tensile Strength | Radial Direction | KN/M | ISO 10319-2015 | 85 | 130 | 220 |
Zonal Direction | KN/M | ISO 10319-2015 | 115 | 120 | 200 | |
Elongation at Break | Radial Direction | % | ISO 10319-2015 | 13 | 12 | 13 |
Zonal Direction | % | ISO 10319-2015 | 8 | 8 | 8 | |
Joint Tensile Strength | KN/M | ISO 10319-2015 | 90 | 100 | 170 | |
CBR | KN | GB/T14800-2010 | 9 | 15 | 20 | |
Dynamic Perforation | MM | GB/T17630-1998 | 8 | 10 | 8 | |
Effective Aperture(O90) | MM | GB/T14799-2005 | 0.45 | 0.4/0.28 | 0.45 | |
Permeability(Q50) | L/m2/s | GB/T15789-2005 | 35 | 14 | 18 | |
UV Resistance | % | ASTM D4355-2014 | 90 | 85 | 85 |
Advantages of Geotube
1. High strength, low deformation
2. Durability: steady property, not easy to resolved, air slaked
and can keep the original property long term
3. Anti-erosion: anti-acid, anti-alkali, resists insects and mould
4. Permeability: could control the sieve size to retain certain
permeability
5. Effective high volume containment
6. Efficient dewatering and volume reduction
7. Cost effective
8. No special equipment required
Product Application
Light Industry, Agriculture and Aquaculture
Geotube bag dehydration technology reduces the water content in the
filtration process, simplifies the water recycling process, and
intercepts more than 90% of the suspended solid particles. It is an
ideal choice for cleaning sludge storage tanks, clarification tanks
and filtering waste projects.
![]() |
