Solid Floating PVC Silt Curtain For Spill Control
Product Description
Permeable floating silt curtain are the premium turbidity products
to keep sediment under control for today's demanding marine
construction and industrial environment. We offer a wide variety of
pervious and impervious oil spill containment boom that meet?
internation requirements .A silt barrier is a land or water based
product designed to contain silt during construction or marine
repair projects. For water areas, Triton floating turbidity
barriers (also known as silt screen, silt booms, or turbidity
curtains) surround and contain suspended silt and allow it time to
settle. For land based jobs, staked silt fence form a barrier for
runoff filtration. Correctly installing these floating silt curtain
in silt retention helps you stay in compliance by containing silt
and reducing stormwater pollution.
Turbidity curtain yellow can be used to control, contain, deflect
or recover floating debris. Built to meet the specific needs and
requirements? these barriers have effectively been used with
hyacinth, duckweed, trash, plastic, cranberries, fish and marine
life, logs and debris. Whether you need a seaweed protection
barrier, trash control, aquatic plant containment or even marine
life control, these yellow floating silt curtain can meet your
needs.
Technical Parameter
PVC Flotation Oil Boom Specification | ||||||||
Model | FOB-650 | FOB-700 | FOB-750 | FOB-800 | FOB-900 | FOB-950 | FOB-1000 | FOB-1100 |
freeboard | 180mm | 260mm | 250mm | 330mm | 325mm | 320mm | 160mm | 250mm |
sea gauge | 320mm | 400mm | 410mm | 540mm | 650mm | 770mm | 340mm | 500mm |
standard length | 20m15m,10m | |||||||
standard | 20KN | 40KN | 55KN | 65KN | 75KN | 85KN | 20KN | 35KN |
strength | ||||||||
scale of submerged weight | 3.9 | 5.6 | 4.9 | 6.2 | 5.6 | 5.5 | 3.2 | 4.2 |
weight | 3.7kg/m | 6.2kg/m | 7.1kg/m | 8.4kg/m | 9.3kg/m | 9.5kg/m | 3.3kg/m | 4.5kg/m |
Max. wave resisted | 0.5m | 1m | 1.5m | 1.8m | 2m | 1m | 0.5m | 0.5m |
Max. wind speed resisted | 10m/s | 15m/s | 15m/s | 18m/s | 18m/s | 20m/s | 10m/s | 10m/s |
Max. flow velocity resisted | 1 | 1.5 | 2 | 2Kn | 2.5Kn | 2.5Kn | 1 | 1 |
20m/60m Packing | 1*1*0.6 | 1.2*1*1 | 1.3*1.1*1.1 | 1.4*1.5*1.2 | 1.4*1.6*1.3 | 1.4*1.7*1.4 | 1.4*1.7*0.8 | 1.4*1.7*1.2 |
Structure:
1. Boom's membrane is PVC double-face coated reinforced fabric.
2. A top ridge rope, middle reinforced belts and a bottom balance
chain on boom sections bear the longitudinal load, and form
concaves both at the skirt in water and at the flexible sections
above water when boom is in a current.
3. There are flexible sections between cross beam like floaters.
4. Easily connect boom sections, which are 20m long.
5. Every section has anchor seats.
Application :
Solid flotation PVC oil boom is a genernal purpose and economic oil
boom that designed to deflect or contain spills or floating debris
for coastal and shoreline .
These booms are suitable for most general use applications and can
be deployed in multi - ple environment e.g. industrial sites
,rivers , ponds ,lakes and near-shore petroleum platforms.
Performance:
1. High strength and long service life. Because of reasonable force
distribution on the boom.
2. Good oil stagnant ability with due to nice posture and high
stability in water.
3. Good wave-response. Easy deployment.
4. Easy to clean and maintain.
