    20m 30m Floating Silt Screens Oil Containment Boom Turbidity Curtains

    Ask Lasest Price
    Brand Name : zhongloo
    Model Number : Floating Silt Curtain
    Certification : ISO9001
    Price : USD 12.6-17.6 per meter
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 30000 meters per Week
    Delivery Time : 10-15 days
    MOQ : 100m
    • Product Details
    • Company Profile

    20m 30m Floating Silt Screens Oil Containment Boom Turbidity Curtains

    Pvc Floating Oil Containment Boom Floating Turbidity Curtains And Silt Curtains


    Product Description

    Permeable floating silt curtain are the premium turbidity products to keep sediment under control for today's demanding marine construction and industrial environment. We offer a wide variety of pervious and impervious oil spill containment boom that meet?internation requirements .A silt barrier is a land or water based product designed to contain silt during construction or marine repair projects. For water areas, Triton floating turbidity barriers (also known as silt screen, silt booms, or turbidity curtains) surround and contain suspended silt and allow it time to settle. For land based jobs, staked silt fence form a barrier for runoff filtration. Correctly installing these floating silt curtain in silt retention helps you stay in compliance by containing silt and reducing stormwater pollution.
    Turbidity curtain yellow can be used to control, contain, deflect or recover floating debris. Built to meet the specific needs and requirements? these barriers have effectively been used with hyacinth, duckweed, trash, plastic, cranberries, fish and marine life, logs and debris. Whether you need a seaweed protection barrier, trash control, aquatic plant containment or even marine life control, these yellow floating silt curtain can meet your needs.


    20m 30m Floating Silt Screens Oil Containment Boom Turbidity Curtains


    Technical Parameter


    PVC Flotation Oil Boom Specification
    ModelFOB-650FOB-700FOB-750FOB-800FOB-900FOB-950FOB-1000FOB-1100
    freeboard180mm260mm250mm330mm325mm320mm160mm250mm
    sea gauge320mm400mm410mm540mm650mm770mm340mm500mm
    standard length20m15m,10m
    standard20KN40KN55KN65KN75KN85KN20KN35KN
    strength
    scale of submerged weight3.95.64.96.25.65.53.24.2
    weight3.7kg/m6.2kg/m7.1kg/m8.4kg/m9.3kg/m9.5kg/m3.3kg/m4.5kg/m
    Max. wave resisted0.5m1m1.5m1.8m2m1m0.5m0.5m
    Max. wind speed resisted10m/s15m/s15m/s18m/s18m/s20m/s10m/s10m/s
    Max. flow velocity resisted11.522Kn2.5Kn2.5Kn11
    20m/60m Packing1*1*0.61.2*1*11.3*1.1*1.11.4*1.5*1.21.4*1.6*1.31.4*1.7*1.41.4*1.7*0.81.4*1.7*1.2



    Advantage:

    1. Good stress state, high overall strength and long service life.
    2. Good water posture, stable, strong oil retention ability.
    3. Good wave riding.Easy to place.
    4. Easy to clean and maintain.
    5. Double-sided coated PVC reinforced plastic cloth is the column material.
    6. Sealing, quick connection, time and labor saving, in line with international standards.
    7. The upper, middle and lower ridges, stiffening belts and counterweight chains are longitudinal force elements. Each section of the oil boom has a fixed anchor seat, so that the skirt of the oil boom forms a concave surface of underwater oil stagnation in the water flow, and the flexible section of the oil boom forms a concave surface of water oil stagnation.
    8. Crossbar type float with flexible sections between floats.
    9. Each section is 20 meters, with convenient intersection connection.


    20m 30m Floating Silt Screens Oil Containment Boom Turbidity Curtains


    FAQ:

    Q:Can you send samples?

    A:Yes, we are very happy to provide you with free samples to check the quality of our products.

    Q:Are you a manufacturer or a trading company?
    A:Our company located in Hefei,Anhui Province,with are registered capital of 52 miion yuan. It is a professional
    manufacturer of Silt curtain and other products. So we have the competitive price with best quality.

    Q:Can you produce the product according to customers' requirements?
    A:Sure,we are professional manufacturer, OEM and ODM are both welcome.

    Q:How long is the delivery time?
    A:General within 3-7 days after receiving the deposit.

    Q:How to control product quality?
    A:Our factory adopts lean management, products from the beginning to the end of the production process have strict qualitycontrol. All products must be strictly tested before packing and shipping.
