Impermeable Floating Silt Curtain Turbidity Boom Geotextile

Anhui Zhonglu Engineering Materials Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Impermeable Floating Silt Curtain Turbidity Boom Geotextile from wholesalers

    Buy cheap Impermeable Floating Silt Curtain Turbidity Boom Geotextile from wholesalers
    • Buy cheap Impermeable Floating Silt Curtain Turbidity Boom Geotextile from wholesalers
    • Buy cheap Impermeable Floating Silt Curtain Turbidity Boom Geotextile from wholesalers

    Impermeable Floating Silt Curtain Turbidity Boom Geotextile

    Ask Lasest Price
    Brand Name : zhongloo
    Model Number : Floating Silt Curtain
    Certification : ISO9001
    Price : USD 12.6-15.5 per meter
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 30000 meters per Week
    Delivery Time : 10-15 days
    MOQ : 100m
    • Product Details
    • Company Profile

    Impermeable Floating Silt Curtain Turbidity Boom Geotextile

    Impermeable Floating Turbidity Silt Curtain For Spill Containment


    Product Description

    Silt curtains (also called turbidity curtains, silt screens or silt barricades) are vertical barriers positioned within the water that function to contain the fine particles of silt that are discharged into the water from dredging, construction or reclamation activities.


    Silt curtains are useful tools in almost any water environment. There are three groups of silt curtains, named type I, type II and type III, with I being the lightest and III the most heavy-duty silt curtain. Qualified professions will analyze a variety of factors such as water flow speed, waves, wind, and project type and duration, to help you to decide which silt curtain is needed for your project.Impermeable Floating Silt Curtain Turbidity Boom Geotextile


    Technical Parameter


    PVC Flotation Oil Boom Specification
    ModelFOB-650FOB-700FOB-750FOB-800FOB-900FOB-950FOB-1000FOB-1100
    freeboard180mm260mm250mm330mm325mm320mm160mm250mm
    sea gauge320mm400mm410mm540mm650mm770mm340mm500mm
    standard length20m15m,10m
    standard20KN40KN55KN65KN75KN85KN20KN35KN
    strength
    scale of submerged weight3.95.64.96.25.65.53.24.2
    weight3.7kg/m6.2kg/m7.1kg/m8.4kg/m9.3kg/m9.5kg/m3.3kg/m4.5kg/m
    Max. wave resisted0.5m1m1.5m1.8m2m1m0.5m0.5m
    Max. wind speed resisted10m/s15m/s15m/s18m/s18m/s20m/s10m/s10m/s
    Max. flow velocity resisted11.522Kn2.5Kn2.5Kn11
    20m/60m Packing1*1*0.61.2*1*11.3*1.1*1.11.4*1.5*1.21.4*1.6*1.31.4*1.7*1.41.4*1.7*0.81.4*1.7*1.2



    Applications:
    1.Block algae barricading applicable to fixed the water wash cloth for a long time, because of its drop quickly, the characteristicsof convenient operation, can be used to prevent because of port and waterway dredging, lakes and offshore oil platforms, such as water, the water civil engineering construction cause the pollution diffusion of turbid water, after the cloth from the surface to the bottom sediment, suspended solids and water form a block freely through the curtain, can not block the flow of water and isolates the clean area and pollution area.

    2.Algae containment can also be used as an antifouling screen, which is an essential equipment to prevent the pollution caused by seabed sediment rising in the process of large-scale displacement of sea water and sediment in reclamation and harbor construction projects.The main means to prevent sediment pollution is to prevent the large area of sediment diffusion

    Impermeable Floating Silt Curtain Turbidity Boom Geotextile


    FAQ:

    Q:Can you send samples?

    A:Yes, we are very happy to provide you with free samples to check the quality of our products.

    Q:Are you a manufacturer or a trading company?
    A:Our company located in Hefei,Anhui Province,with are registered capital of 52 miion yuan. It is a professional
    manufacturer of Silt curtain and other products. So we have the competitive price with best quality.

    Q:Can you produce the product according to customers' requirements?
    A:Sure,we are professional manufacturer, OEM and ODM are both welcome.
