    Plastic Wall Retaining Slope Protection Geocell Gravel Stabilizer Net

    Ask Lasest Price
    Brand Name : OEM
    Model Number : Plastic HDPE Geocell
    Certification : ISO certificate
    Price : USD0.58-USD3.06 per square meter
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 60, 000 Square Meters Per Day
    Delivery Time : 7-10 working days
    • Product Details
    • Company Profile

    Plastic Wall Retaining Slope Protection Geocell Gravel Stabilizer Net

    Plastic Driveway Gravel Grid Soil Stabilization Wall Retaining Geocell for Slope Erosion Controll


    Plastic Driveway Gravel Grid geocell Description:


    Geocell is a net-shaped cell structure made from high density polyethylene by welding high intensity thermoplastic sheet, it is flesible to fold during transportation, stretching out and being filled with stone or concrete during service, and fourming into structure with powerful lateral confinement and rigidity.


    HDPE plastic honeycomb hdpe geocell gravel grid Features:
    1) Light material , resistant to wear , stable in chemical properties , anti-aging , resistant to acids and alkalis, applicable to different soil and desert and other geological conditions .
    2)High limit on lateral direction , anti-skidding , anti-deformation , effectively enhance the supporting ability and scattered load function of roadbed .
    3)High carrying capacity and good dynamic performance and high erosion ability .
    4)The geometry size can be changed to meet different needs of the project , such as height and welding distance
    5)Retractable and small loading volume , convenient joint , speed construction .
    6)Local material can be used during construction , reduce the construction cost , easy to be transported after folding together.


    Technical Parameters:
    Material PropertiesUnitTest Method
    Cell Depthmm75100150200
    Polymer Densityg/cm30.935-0.965ASTM D 1505
    Environmental Stress Crack ResistanceHours>400ASTM D 5397
    Environmental Stress Crack ResistanceHours6000ASTM D 1693
    Carbon Black Content%1.5% - 2.0%ASTM D 1603
    Nominal Sheet Thickness Before Texturingmm1.27 -5%,+10%ASTM D 5199
    Nominal Sheet Thickness After Texturingmm1.52-5%,+10%ASTM D 5199
    Strip Puncture ResistanceN450ASTM D 4833
    Seam Peel StrengthN1065142021302840EN ISO13426-1B
    Seam Efficiency%100GRI-GS13
    Nominal Expanded Cell Size (width x length)mm320x287,475x508 etc
    Nominal Expanded Panel Size (width x length)m2.56x8.35, 4.5x5.0, 6.5x4.5, 6.1x2.44

    FEATURES:
    1. High Grade Raw Material to Ensure the Product Performance
    Use virgin HDPE material to assure consistent, reproducible, and long-lasting performance.
    2. Ultrasonic Wedling to Ensure the Strength of the Seam
    Strong weld continually tested to project assurance.
    3. Honeycomb Structure to Bearing Heavy Load
    Prevent horizontal movement, and increase both shear strength and bearing capacity.
    4. Proformed Hole to Allow Water to Get Through
    Prevents erosion, and allow water flow.


    HDPE Geocell Application:

    1. Slope Protection
    The geocell Slope protection system prevents sliding or sloughing off by providing sufficient weight at the foot and or along the face of the slope.

    2. Earth Protection
    The geocell earth protection system minimizes and eliminates erosion actions of wind and water on exposed soils.

    3. Channel Protection
    The geocell channel protection system protects channel slops from soil erosion and confines the infill material that from the channel bed and banks.

    4. Ground Stabilization
    The Geocell Ground Stabilization System provides cost-effevtive solution to ground stabilization project.

    5. Vegetation Retention
    The Geocell Vegetation retention system`s horizontal create a natural environment for sustainable vegetation and allow water to collect through the wall fascia, and minimizing run off.


    Load Support
    Cellular Confinement Systems have been used to improve the performance of both paved and unpaved roads by reinforcing the soil in the subgrade-base interface or within the base course. The effective load distribution of geocell creates a strong,stiff 3D
    cellular mattress which can reduce vertical differential settlement into soft subgrades, improves shear strength, and enhances load-bearing capacity, while reducing the amount of aggregate material required to extend the service life of roads.
    Slope Pretection

    The three-dimensional lateral confinement of Cellular Confinement Systems along with anchoring techniques ensures the long-term
    stability of slopes using vegetated topsoil, aggregate or concrete surfacing
    Gruound Stabilisation

    Cellular Confinement Systems strengthen the aggregate infill, thereby simultaneously enabling the use of poorly graded inferior material for infill as well as reducing the structural support layer thickness.Typical stabilisation applications include
    reinforcement of base and subbase layers in flexible pavements, including: roads, railway substructure and ballast confinement; working platforms in intermodal ports; airport runways.
    Retaining Wall


    Cellular Confinement Systems provide steep vertical mechanically stabilized earth structures (either gravity or reinforced walls) for steep faces, walls and irregular topography
